TekBIO Laminar Air Flow

In Stock
Made In India

We have a range of high-performance vertical Laminar Air Flow cabinets. Modular construction, combining aesthetic appeal with functional utility and efficiency. These are designed to meet the filtration, illumination, Noise & Vibration requirements and US Federal Standard 209 B (BS5295) Providing air to meet class 100 (class I) conditions, to the extent applicable. It is Ideal for microbiological manipulations. work with bioassays sterility testing & research work. Vial filling &bunging operation in parenteral units & for general dry-process semiconductor industry etc. Provides a comfortable 'sit down' working position for the operators.

All laminar flow clean air cabinets are basically constructed out of thick CRC sheet - powder coated or thick teak wood board which is termite and insect-proof. The work table is made ofS.S.304 and side panels of thick transparent plexiglass.

Air Flow and Filtration:
The laminar airflow principle involves double filtration of air. Atmospheric air is drawn through pre-filter and is made to pass through highly effective HEPA (High-Efficiency Particulate Air) Filtershaving an efficiency rating as high as 99.99% with cold and 99.97% with hot DOP, thus retaining all air-borne particles of size 0.3 micron and larger. Double filtered air blows in laminar flow through the work table at the DB-designed velocity of 90 ft. min ± 20%.

Blower Motor Assembly:
Duly balanced, direct-drive motor blower units are sized to provide adequate airflow volume over the entire surface of the HEPA filter. Fitted with standard make the motor and operates with minimum noise level i.e. lower than 6dB on the scale and vibrationless than 2.5 um.

Work area properly illuminated by diffused, glare-free fluorescent Light.

Available Working Sizes:

  • 2ft x 2ft x 2ft
  • 3ft x 2ft x 2ft
  • 4ft x 2ft x 2ft
  • 6ft x 2ft x 2ft
  • Custamize sizes are available.

TekBIO Labsolutions (P) Ltd.
403/4th Floor Kush Complex,
Naranpura Cross Road, Naranpura,
Ahmedabad, Gujarat, India.
Email: [email protected][email protected][email protected]
Mobile: 9824097792, 9427384850, 9033111473
