Zybio Hematology Analyzer Z5 Technical Specification
- Principal: Flow cytometry + tri-angle laser scatter + chemical dye method for WBC 5-diff differential analysis and WBC counting Impedance method for RBC and PLT counting. Cyanide free reagent for HGB measurement.
- Mode : CBC, CBC+DIFF
- Throughput : 60 samples per hour
- Parameters : 25 reportable parameters: WBC, Lym%, Mono%, Neu%, Bas%, Eos%, Lym#, Mono#, Neu#, Bas#, EOS#, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD, PLT, MPV, PCT, PDW, P-LCR, P-LCC. 4 research parameters : ALY %, ALY#, LIC%, LIC#
- Graph : 3-D Diff scatter gram, 3 2-D Diff scatter gram, 2-D BASO scatter gram, 3 histograms for WBC and PLT
- Sample Mode : venous whole blood, Capillary whole blood, Pre-diluted.
- Sample Volume : Venous/Capillary whole blood:18 µL
- Reagent : Z5 LD Lyse, Z5 LB Lyse, Z5 DN Diluent, Probe Cleanser
- Calibration : Manual Calibration, Auto Calibration : Fresh Blood, Calibrator
- QC Rule : L-J, X-B
- Screen : 8.4 - inch touch screen
- Interface : 4 USB portfor external printer, external barcode scanner, mouse, keypad, etc., 1 network port, HL7 protocol, support bilateral LIS.
- Storage Capacity : ≥50,000 results including numeric and graphical information
- Power Supply : (100-240)V, 50/60Hz, 200 VA
- Operation Environment : Temperature : (10-30)° C, Humidity : (20-85)%, Atmospheric Pressure : (70-106)kPa
- Weight : 25 Kg
- Dimension (mm ) : 230(W)* 435(D)*435(H)
